Upgrading PMF 9.x to latest fix pack (Cloud)


This topic is meant for upgrading PMF Version 9.1 or 9.2 to the latest PMF fix pack level.

Upgrade scenario

  • Persistent Mobile Foundation 9.1 → Persistent Mobile Foundation 10.x
  • Persistent Mobile Foundation 9.2 → Persistent Mobile Foundation 10.x

Procedure

Proceed as follows.

  1. Download the PMF-OpenShift-Pak-<version>.tar.gz package.

    a. Extract PMF-OpenShift-Pak-<version>.tar.gz package by using the following command.

    tar -xvzf PMF-Openshift-Pak-<VERSION>.tar.gz

    Note: The Elasticsearch component has being replaced by OpenSearch in PMF 10.x. For more information, see Installing and configuring OpenSearch.

  2. Migrate the Elasticsearch data to OpenSearch. For more information, see Migrating Elasticsearch data to OpenSearch.

    a. Go to tools/elasticsearch-opensearch-migration directory of the extracted package and install application prerequisites by running the following command.

    export PATH=/< extracted path>/tools/elasticsearch-opensearch-migration/node-linux-x64/bin:$PATH
cd /<extracted path>/tools/elasticsearch-opensearch-migration/analytics-data-migration-tool
npm install
node -v

    b. Update the config.json parameters as required.

    Optional: Data exported from Elasticsearch can be imported into a different tenant in OpenSearch, to do so proceed as follows.

    i. Create tenant.xml file by using following details.

    <server>
<jndiEntry jndiName="analytics/tenant" value='<TENANT-NAME>'/>
</server>

    ii. Create a ConfigMap using the tenant.xml file by using the following command.

    oc create ConfigMap analytics-custom-config --from-file=tenant.xml

    iii. Provide the created ConfigMap to the Analytics component in the charts_v1_mfoperator_cr.yaml CR file.

    customConfiguration: "analytics-custom-config"

    c. Export Elasticsearch data by using the following command.

    cd /<extracted path>/tools/elasticsearch-opensearch-migration/analytics-data-migration-tool
npm run export -- -b 100

    d. Migrated data to OpenSearch by using the following command.

    npm run migrate -- -b 100

    e. Validate migration by using the following command.

    npm run migrate -- -v

  3. Upgrade components for PMF.

    a. Go to deploy directory of the above extracted package and modify following deployment of YML files.

    • service_account.yaml - Provide created imagePullSecret.
    • role_binding.yaml - Provide namespace.

    • charts_v1_mfoperator_cr.yaml

      • Copy the values from the old version of charts_v1_mfoperator_cr.yaml to the new charts_v1_mfoperator_cr.yaml file.

      • Add values for VAPT properties as per your requirement. For more information, see config.properties file parameters.

      • Add values for OpenSearch properties in the Analytics component.

        opensearch:
      url: "<OpenSearchURL>"
      username: "<OpenSearchUser>"
      password: "<OpenSearchPassword>"

      • Provide create push custom ConfigMap, In version 10.x, we introduced support for multiple apps with different FCM accounts. To use the push feature in 10.x, proceed as follows.

        1. Create ConfigMap using different fcm accounts JSON files by using the following command.

             oc create ConfigMap push-custom-config --from-file=app1.json,app2.json,appx.json...

        2. Provide created ConfigMap to push components.

          customConfiguration: " push-custom-config".

        3. Create ConfigMap to map environment variable to JSON files by using the following command.

             oc create ConfigMap push-fcm-v1-ConfigMap
   --from-literal=ENV_APP1=/opt/ibm/wlp/usr/servers/mfpf-push/configDropins/overrides/app1.json
   --from-literal=ENV_APP2=/opt/ibm/wlp/usr/servers/mfpf-push/configDropins/overrides/app2.json
   --from-literal=ENV_APPx=...

    c. Go to deploy directory and apply following commands.

    oc apply -f crds/charts_v1_mfoperator_crd.yaml
oc apply -f service_account.yaml
oc apply -f role.yaml
oc apply -f role_binding.yaml
oc apply -f deploy/operator.yaml

    d. Run the following command to upgrade components CR once PMF operator pod is up and running.

      oc apply -f crds/charts_v1_mfoperator_cr.yaml

  4. Verify that the consoles are up and running by using the following URLs.

    <<protocol>>://<<hostname>>/mfpconsole

▲
